HCI IG5262GYSA DUP SPD RCPT, IG, 15

Manufacturer: Hubbell Wiring Device | Catalog # IG5262GYSA | Cooper Electric Part # 961491
$276.29/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Installation / Instruction Manual
IG TVSS Duplex Receptacle with Light and Alarm, 15A 125V, 5-15R, Gray

Technical Information

Amperage
15 Amp
Applications
Decorator Duplex with Light and Alarm
Current
15 Amp
Frequency
60 Hz
Grade
Standard
Grounding
Isolated
Material
Nylon
Mounting Type
Screw
NEMA
5-15R
Number of Phases
1 Phase
Number of Poles
2 Pole
Number of Wires
3 Wire
Operating Temperature
0 To 60 degrees C
Response Time
5n s
Size
Standard
Standard
C22.2 No. 42,CSA,File E2186,UL,UL Standards 498
Style
Isolated Ground
TC Connection
Terminal Screws
Temperature Rating
0 - 60 degrees C
Type
Straight Blade, Decorator
Voltage
125 Volt
Wire Count
3

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
SpikeShield®

General Product Info

12-Digit UPC
783585060590
Class
Normal and Common Mode
Color
Gray
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
GTiN
00783585060590
Product Series
Specification Grade
Product UPC
78358506059
Weight
0.25 lb

Dimensions

Height
1.9 Inch
Length
4.4 Inch
Width
2.400 in

Certifications and Compliance

Certifications
UL Listed File E2186
Country of Origin
China
Features
  • Automatic self-grounding staple
  • Distinctive surge symbol provides quick identification
  • Power-on indicator light verifies that power is available
  • Alert alarm sounds when surge protection is no longer functioning
  • Isolated Ground
