Product image for Brady PS-125-2-WT-S PermaSleeve Polyolefin Wire Marking Sleeves, White, 0.125" Dia x 2" W, Roll of 500 Each
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Image thumbnail 3
Image thumbnail 4
Image thumbnail 5
Email

Brady PS-125-2-WT-S PermaSleeve Polyolefin Wire Marking Sleeves, White, 0.125" Dia x 2" W, Roll of 500 Each

Manufacturer: Brady Worldwide, Inc. | Catalog # PS-125-2-WT-S | Cooper Electric Part # 954465
$369.99/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet
PermaSleeve® PS Heat-Shrink Polyolefin (B-342) wire marking sleeves combine speed, ease of use, and permanence to create long-lasting, high quality identification.

Technical Information

Applications
For Cable and Wire Marking
Cable Size
22-16 AWG
Conductor Size
22-16 AWG
Material
Polyolefin
Max Operating Temperature
275 F
Max Temperature
135 degrees C
Min Operating Temperature
-67 F
Min Temperature
-55 degrees C
Shrink Ratio
3:1
Temperature Rating
-94 to 267 degrees F
Type
Self-Extinguishing, Single-Side Printable
Wire Size
22-16 AWG

Manufacturer Information

Brand
Brady Corporation
Sub Brand
PermaSleeve®

General Product Info

12-Digit UPC
662820321439
Color
Matte White
Finish
Matte
GTiN
00662820321439
Product UPC
66282032143
Qty per Row
1
Shape
Rectangle
Used With
R2000, R4300, R4502S, R5000, R6600, R6700 Series Ribbon, Brady IP® Series Thermal Transfer Label Printer, Bradyprinter™ PR Plus Series Thermal Transfer Label Printer

Dimensions

Diameter
1/8 Inch
Height
0.235 Inch
Length
0.235 Inch
Roll Width
2 in
Width
2 in

Certifications and Compliance

CA Prop65 Warning
Y
Features
  • 3:1 heat shrinkable sleeve fit snugly around wires for maximum insulation protection and permanent identification
  • Fade-resistant and smudge-proof for superior aesthetic appearance
  • Cold resistant and flame-retardant with an operating temperature of -67°F to 275°F (-55°C to 135°C)
  • Meets SAE-AMS-DTL-23053/5C (Class 1), SAE-AS-81531, MIL-STD-202;RoHS Compliant;and UL Recognized
