Lutron MSCL-VP153M-WH Maestro CL White 1-Pole Multi-Location Vacancy Sensing Dimmer

Manufacturer: Lutron | Catalog # MSCL-VP153M-WH | Cooper Electric Part # 918000
$58.70/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet
Maestro LED+ passive infrared vacancy sensor that automatically control the lights in an area in white

Technical Information

Applications
Lighting Control
Body Material
Plastic
Enclosure
Plastic
Enclosure Material
Plastic
Lamp Type
Incandescent
Mounting Type
Wall Box
Operating Temperature
32 To 104 degrees F
Power Rating
600/400 W
Power Supply
120 V
Sensing Range
900 ft2 (82 m2) major motion coverage/400 ft2 (36 m2) minor motion coverage
Standard
CUL,Title 20/24 Certified,UL
Temperature Rating
0 degrees C to 40 degrees C
Type
Multi-Location, 3-Way, 1-Pole
Voltage
120 Volt

Manufacturer Information

Brand
Lutron Electronics Company
Sub Brand
Maestro

General Product Info

12-Digit UPC
784276055116
Color
White
Environmental Conditions
0 - 90%
Finish
Gloss
GTiN
00784276055116
Product UPC
78427605511

Certifications and Compliance

Country of Origin
China
Features
  • Includes (1) Maestro LED+ Motion Sensor/Dimmer Switch, Vacancy Only; Gloss Finish
  • Rated for 150W dimmable LED or 600W Incandescent/Halogen bulbs; No Neutral or Ground required
  • Screw Terminal or Push-in Installation; 120V
  • Single Pole/Multi-location dimming with Lutron Maestro Companion dimmers (MA-R/MSC-AD); Compatible with an existing 3-way switch
  • Features passive infrared (PIR) motion detection with exclusive Lutron XCT Technology for fine motion detection, which is 2-3x better at picking up motion than other manufacturers
  • 180-degree sensor field of view (900 sq ft major motion & 400 sq ft minor motion coverage); Tamper-resistant lens
  • Easy button programming mode available to customize dimmer and sensor functions such as timeout, fade-off rate, and sensitivity
  • Complies with Title 20/24 Section 110.9 for automatic shutoff
  • Pairs perfectly with Lutron Claro wall plates for consistent color matching (wall plates are sold separately)Available in 10+ colors
  • Available in 10+ colors; Pairs perfectly with Lutron Claro wall plates for consistent color matching (wall plates are sold separately)
  • Passive infrared sensors that automatically control the lights in an area
  • These sensors detect heat from occupants moving within an area to determine when the space is occupied
  • Combines a Maestro LED+ dimmer with a vacancy sensor
  • Controls CFL, LED, incandescent, and halogen load types
  • Passive infrared motion detection with exclusive Lutron XCT Technology for fine motion detection
  • 180 degree sensor field-of-view
  • Up to 30 ft x 30 ft (9 m x 9 m) [900 ft2 (81 m2)] major motion coverage and 20 ft x 20 ft (6 m x 6 m) [400 ft2 (36 m2)] minor motion coverage
  • Adjustable timeout (1, 3, 5, 15, or 30 minutes) and high/low sensitivity adjustment
  • Adjustable settings for auto-on light level (occupied level): 100 %, 50 %, last light level, or locked preset light level
  • Off warning fades lights to off over a period of 10 seconds
  • Advanced Maestro dimmer features available (locked preset, fade-to-on, and fade-to-off, etc.)
  • Works with a single standard mechanical 3-way switch or up to 9 companion dimmers/switches
Standards and Certifications
  • UL
  • NOM
  • TITLE20
  • TITLE24
  • cUL
  • Title 20/24 certified
