Product image for Hoffman ADIN3PA42 DIN 3 Rail with Self-Adhesive, 1.7x1.5x0.55 inch, Black, Plastic
Email

Hoffman ADIN3PA42 DIN 3 Rail with Self-Adhesive, 1.7x1.5x0.55 inch, Black, Plastic

Manufacturer: Hoffman | Catalog # ADIN3PA42 | Cooper Electric Part # 913788
$33.82/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet
DIN 3 Rail with Self-Adhesive is designed to directly mount small DIN rail mountable components or use as DIN 3 rail holder. Use in tight spaces where installation of a DIN rail is not possible. Industrial grade adhesive is used to avoid hole drilling with fast installation. Each unit can hold up to 1.1 lbs. (500g) in weight. Fasteners may be used for increased load rating. DIN 3 Rail with Self-adhesive can only be mounted on smooth surfaces, e.g. metals, lacquered surfaces and plastics (except polyethylene, polypropylene and rubber). The surfaces must be dry and free from dust, oil, separating agents and other contamination.

Technical Information

Applications
Controls and Drives
Material
Plastic
Size
0.47x1.65x1.42 in
Standard
Material Conforms To UL 94V-0
Type
Mounting Accessories

Manufacturer Information

Brand
nVent Hoffman
Sub Brand
Hoffman

General Product Info

12-Digit UPC
783510260927
Color
Black
Finish
Matte
GTiN
00783510260927
Product UPC
78351026092
Weight
1 lb

Dimensions

Depth
1.42 Inch
Height
1/2 Inch
Length
6-1/4 Inch
Width
4.00 in
Features
  • DIN 3-style, symmetrical
  • Constructed from UL 94V-0 rated black plastic
  • Each unit can hold 1.1 lbs. (500g) after a 24-hour waiting period
  • Mounting self-adhesive (non-aging, high-performance adhesive strip)
  • Optional screw mount; five 10-32/M5 screws are provided
  • Hole pattern 0.5 in. (12.8 mm) distance, Ø 0.14 in. (3.6mm)
  • Five self-adhesive DIN rails per kit
  • Operating / Storage temperature -49 F to +158 F (-45 C to 70 C)
