Erico 569251 Single Pole Dist. Block, 400 A UL/CSA, 2 Cables Line, 12 Cables Load, Aluminum

Manufacturer: Erico, Inc | Catalog # 569251 | Cooper Electric Part # 903383
$49.04/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Product Brochure
Primary device for easy assembly between a wide range of conductors to perform electrical power distribution. Single Pole Dist. Block UD-400212AL, Aluminum.

Technical Information

Amperage
400 Amp; 400 Amp
Applications
Power Connections
Enclosure Rating
IP20
Material
Aluminum
Number of Conductors
2 Cables; 12 Cables
Number of Poles
1 Pole
Size
1.99x3.79x2.2
Standard
UR,EAC,CUR
Temperature Rating
185 Deg F
Type
Distribution Blocks
Voltage
1,000 VAC, 1,500 VDC; 1,000 VAC/DC

Manufacturer Information

Brand
nVent Eriflex
Sub Brand
ERIFLEX

General Product Info

12-Digit UPC
782856687610
Color
Blue,White
Environmental Conditions
86 To 167 Deg F
Finish
Tinned
GTiN
00782856687610
Product UPC
78285668761
Weight
0.17 kg
Certifications
  • cUR CSA C22.2 No. 158
  • CSA CSA C22.2 No. 158
  • CE, ERIFLEX UD EN 60947-7-1
  • UR ANSI/UL 1059
  • EN 45545 EN 45545-2:2013
  • UKCA, ERIFLEX UD EN 60947-7-1
Features
  • Tinned copper or aluminum block allows for copper or aluminum conductor direct connections, or using ferrule
  • Screw retaining cover is hinged and removable
  • Design allows for visual inspection of conductor and confirmation of connection
  • Modular snap-together blocks for building multi-pole power blocks
  • Easily clips onto DIN rail or mounts to panel with screws
  • 95% fill ratio
  • RoHS compliant
  • Conforms to EN 45545 obtaining an HL3 classification for chapter R23 and HL2 classification for chapter R22
  • Halogen free
