LITH LE S 1 R EL N Signature die-ca

Manufacturer: Lithonia Lighting | Catalog # LES1RELN | Cooper Electric Part # 861717
$368.94/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Buy American Compliant Buy American Compliant Product Spec Sheet Safety Data Sheet
Ideal for applications requiring attractive die-cast aluminum signage, superior illumination and low energy consumption

Technical Information

Applications
Automotive & Parking,Education,Government,Healthcare,Hospitality,House Of Worship,Manufacturing,Offices & Banks,Residential,Retail,Sports And Recreation,Transportation,Warehouses
Lamp Type
LED
Material
Aluminum
Mounting Type
Surface
Number of Lamps
1
Power Source
Hardwired
Standard
CA Title 20,NFPA 101,NFPA 70,ULBAA
Type
Emergency Exit Sign
Voltage
120 Volt
Wattage
2 Watt

Manufacturer Information

Brand
Lithonia Lighting

General Product Info

12-Digit UPC
753573754374
Color
Silver
Environmental Conditions
Indoor,Outdoor
Finish
Brushed
Fixture Type
Emergency Exit Unit (aka Combo), Exit Sign
GTiN
00753573754374
Housing Color
Silver
Letter Color
Red
Product Type
Emergency Exit Sign
Product UPC
75357375437
Shape
Square
Weight
1.69 lb

Dimensions

Height
4 Inch
Length
12 Inch
Warranty Length
5 yr
Width
8.5 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
Mexico
Features
  • The Signature Exit is durable, yet attractive with a die-cast aluminum housing. It features precise edges, clean lines and no exposed hardware.
  • Low energy consumption red exit consumes std .81W, 1.3W (120V), green exit consumes std is 1W, 1.5W (120V). Universal input voltage capabilities (120V through 277V, 50 or 60 HZ)
  • Two-state constant-current charger maximizes battery life and automatically recharges after battery discharge. Test switch provided for manual testing. Self-diagnostic testing for five minutes every 30 days, 30 minutes at 180-day interval, and 90 minutes
  • UL damp location listed 50°F - 104°F (10°C - 40°C). Meets UL 924, NFPA 101 (current Life Safety Code), NEC and OSHA illumination standards. North Carolina Department of Insurance.
  • Universal mounting (top, end or back). Double face available with top or end mounting only.
  • The typical life of the exit LED lamp is 10 years, based on continuous operation. Unique LED lamp platform accommodates both single-face and double-face exits.
  • Fully overlapping light seal prevents light leaks. Universal directional chevron knockouts are completely concealed and easily removed. Hinged faceplate and spring latches for easy lamp compartment access, no exposed hardware.
  • : Battery: Sealed, maintenance-free nickel-cadmium battery delivers 90 minutes capacity to lamp.
  • 5-year limited warranty
Application
  • Automotive & Parking
  • Education
  • Government
  • Healthcare
  • Hospitality
  • House of Worship
  • Manufacturing
  • Offices & Banks
  • Residential
  • Retail
  • Sports and Recreation
  • Transportation
  • Warehouses
Standard
  • NFPA 101
  • NFPA 70
  • ULBAA and BABA
  • CA Title 20
Mounting
  • Surface
