SEPCO MC100G 1IN MI HOT DIPPED C MOGUL W/ROLLER C&G

Manufacturer: Steel Electric Products | Catalog # MC100G | Cooper Electric Part # 763188
$11,216.29/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet

Technical Information

Trade Size
1 Inch

Manufacturer Information

Brand
Steel Electric Products

General Product Info

12-Digit UPC
785994100393
Product UPC
78599410039
Features
  • Exclusive built-in rollers facilitate cable pulling
  • from sizes 1 1/4 4.
  • Smooth, rounded integral bushing in each hub
  • protects conductor insulation.
  • Accurately taped, tapered threads for tight, rigid
  • joints and ground continuity.
  • Covers have captive stainless steel screws to
  • speed installation, prevent freezing of screws.
  • Length Requirement: distance between
  • centerline of each hub bushing (conduit stop)
  • exceeds eight times the trade diameter of the
  • conduit per NEC 314.28(A)(2).
Application
  • Larger body size facilitates pulling of large and
  • heavy conductors. Specially designed raised
  • cast covers provide additional wiring area.
  • SEPCO Moguls are used for pulling straight,
  • 45° or 90° angle turns and/or making taps and
  • splices.
Standard Materials
  • Bodies and Covers: Malleable Iron
  • Gaskets: Neoprene
  • Screws: Stainless Steel
Standard Finish
  • Bodies and Covers: Hot-Dipped Galvanized
UL Listed
  • E198259
