Product image for Trac 12 Conix MR16 Track Head - White
Image thumbnail 0
Image thumbnail 1
Email

Trac 12 Conix MR16 Track Head - White

Manufacturer: Juno Lighting | Catalog # TL106 WH | Cooper Electric Part # 732269
$126.46/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet
The stylish Conix lampholder, featuring Juno's proprietary wishbone yoke design, possesses a fully enclosed lamp housing and can rotate more than 360 degrees to eliminate aiming dead spots. The Conix Trac 12 low voltage lampholder is designed to use 50-watt MR16 halogen lamps. Each fixture includes an integral snoot that is designed to simultaneously accept up to 2 light control accessories.

Technical Information

Applications
Trac Lighting
Bulb Included
No
Lamp Type
Incandescent
Lamp Wattage
50 WTT
Number of Lamps
1
Style
Commercial
Voltage
12/24 VAC
Wattage
50 Watt

Manufacturer Information

Brand
Juno Lighting
Sub Brand
Juno

General Product Info

12-Digit UPC
661209122964
Collection
Trac 12 Conix
Color
White
Finish
White
Fixture Type
Incandescent Low Voltage
GTiN
00661209122964
Product UPC
66120912296
Weight
0.93 Pound

Dimensions

Depth
4 Inch
Height
6-1/2 Inch
Width
3 Inch
Description
  • Vertical aiming locking screws secure lampholder position during relamping cycles
  • Greater than 360-degree horizontal rotation eliminates aiming dead spots; 90-degree vertical aiming capability
  • UL Listed, CSA Certified
  • Lens can be used with up to two 1-3/4-inch accessories simultaneously
  • Includes 20-50W MR16 lamps and ceramic bi-pin socket
Compatible Systems
  • Trac 12 Low Voltage System
  • Trac 12/25 Low Voltage System
