Blackburn CF1010-1 2 to 1/0 AWG Copper Compression H-Tap Connector

Manufacturer: Blackburn / Thomas & Betts | Catalog # CF1010-1 | Cooper Electric Part # 678720
$11.48 /ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet
Copper H-Type Compression Connector Main: 1/0, 1, 2 Stranded Copper, Tap: 1/0, 1, 2 Stranded Copper

Technical Information

Bolt Size
No Bolt
Conductor Size
1-1/0 AWG
Conductor Type
Crimp
Insulated?
No
Material
Copper
Size
27/32 inch Length
TC Connection
Compression
Type
Parallel, Short Sleeve
Wire Size
292-.373 in

Manufacturer Information

Brand
ABB
Sub Brand
Blackburn®

General Product Info

12-Digit UPC
783786093366
Finish
Bare
GTiN
00783786093366
Housing Material
Copper
Product UPC
78378609336
Used With
Round, Solid and Stranded Conductors

Dimensions

Length
27/32 Inch
Features
  • Full length tab makes installation easy. Installs with standard compression tools and dies.
  • RUS accepted.
  • Efficient design requires less crimping force.
  • Made of pure electrolytic copper to provide hight conductivity.
Notes
  • Decimal dimensions are for conventional conductor, not Copperweld or Alumoweld.
