Product image for Square D MG24552 4-Pole 6 Amp 480 Star/277 Volt Thermal Magnetic Supplementary Protector
Image thumbnail 0
Image thumbnail 1
Email

Square D MG24552 4-Pole 6 Amp 480 Star/277 Volt Thermal Magnetic Supplementary Protector

Manufacturer: Square-D / Schneider | Catalog # MG24552 | Cooper Electric Part # 625096
$416.00 /ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Brochure Product Catalog Page Product Spec Sheet
Schneider Electric,SUPPLEMENTARY PROTECTOR 480Y/277V 6A 4P,-30 to 70°C (-22 to 158°F),2.48 in,3.00 in,3.19 in,4-Poles,480Y/277V,5 kA @ 480Y/277 VAC,50/60 Hz,6 A,DIN Rail Mount,Line Box Lug - Load Box Lug,Multi 9,Multi 9 - C60,Multi 9 - C60N Circuit Breaker,Overcurrent protection within appliances or electrical equipment where branch circuit breaker protection is provided or not required,Relative Humidity 95 at 131°F (55°C),UL Certified, IEC Rated

Technical Information

Amperage
6 Amp
Applications
OVERCURRENT PROTECTION WITHIN APPLIANCES OR ELECTRICAL EQUIPMENT WHERE BRANCH CIRCUIT BREAKER PROTECTION IS PROVIDED OR NOT REQUIRED
Frame
MULTI 9 - C60
Interrupt Rating
5 kAIC
Mounting Type
Clip-On
Number of Poles
4 Pole
Operating Temperature
-30 TO 70degrees C (-22 TO 158degrees F)
Standard
CSA C22.2 No 235,EN/IEC 60947-2,GB 14048.2,UL 1077
Strip Length
0.55 in
TC Connection
LINE: BOX LUG - LOAD: BOX LUG
Trip Type
D
Type
MULTI 9 - C60N CIRCUIT BREAKER
Voltage
240 Volt

Manufacturer Information

Brand
Schneider Electric
Sub Brand
MULTI 9

General Product Info

12-Digit UPC
785901881513
Color
Gray
Environmental Conditions
RELATIVE HUMIDITY: 95 AT 131F (55C)
GTiN
00785901881513
Product UPC
78590188151
Weight
0.73 lb

Dimensions

Depth
2.87 Inch
Height
3.19 Inch
Length
3 Inch
Warranty Length
18 mth
Width
2.83 in

Certifications and Compliance

Certifications
CCC,CSA,IEC,UR
Country of Origin
France
