Ilsco PBTD-4-250-M Nimbus Insulated Aluminum Multi-Tap Connector, Conductor Range 250-6, 4 Ports, Dual Sided Entry, Mountable, Tin Plated, UL, CSA

Manufacturer: Ilsco | Catalog # PBTD-4-250-M | Cooper Electric Part # 624936
$198.83/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet
Nimbus Mountable Insulated Multi-Tap Connector Dual Side Entry, Mechanical connection, Dual Rated, Aluminum material, Tin plated connector,2 mounting hole(s), mounting hole spacing 4.65 in., UL 486A/B Listed, C22.2 No. 65-03, Copper/Aluminum Primary Conductor 250 kcmil - 6 Str, Contains DE-OX®, 4 conductors, 4 ports/wireways, Plastisol insulation, Drive Type Main 5/16 Internal Hex, rated for 600 V, primary color Black, 1 poles,

Technical Information

Amperage
290 Amp
Applications
Mountable Insulated Multi-Tap Connector Dual Side Entry
Conductor Material
Aluminum,Copper
Conductor Size
6 AWG-250 kcmil
Conductor Type
Stranded
Connection Type
Mechanical
Material
Aluminum
Mounting Hole Size
0.266 in
Number of Conductors
4
Number of Holes
2 Hole
Number of Ports
4
Standard
CSA,E2186,UL
TC Connection
Mechanical
Temperature Rating
-45 to 90 degrees C
Type
Insulated, Mountable, PBTD
Voltage
600 Volt

Manufacturer Information

Brand
Ilsco
Sub Brand
Nimbus®

General Product Info

12-Digit UPC
783669080971
Color
Black
Environmental Conditions
Cold temperature rated to -45C
Finish
Tin Plated
GTiN
00783669080971
Product UPC
78366908097
Weight
0.769 lb

Dimensions

Height
2.197 Inch
Length
5.814 Inch
Width
2.318 in
