Product image for Square D 9050AO12DV02 120 VAC 60 Hz Coil 15 Amp 1NO 1NC 0.1 Second to 1 Minute Pneumatic Timer
Image thumbnail 0
Image thumbnail 1
Email

Square D 9050AO12DV02 120 VAC 60 Hz Coil 15 Amp 1NO 1NC 0.1 Second to 1 Minute Pneumatic Timer

Manufacturer: Square-D / Schneider | Catalog # 9050AO12DV02 | Cooper Electric Part # 605035
$675.00/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page
9050A NEMA pneumatic timers are designed for very rugged applications where precise timing is not required. They are available in on delay and off delay versions. Timing range is from 0.1 to 60 seconds. These timers can have timed and instantaneous contacts. They are controled by a variety of VAC coils. 9050A pneumatic timers are UL Listed and CSA Certified.

Technical Information

Contact Configuration
TIME DELAYED 1 NO + 1 NC-INSTANTANEOUS 2 NO + 2 NC
Contact Rating
15 A,600 V AC
Current
15 Amp
Operating Temperature
68-104 Adegrees F
Size
102 MM,111 MM,67 MM
TC Connection
SCREW-CLAMP TERMINALS
Type
SPDT,TIMER

Manufacturer Information

Brand
Square D

General Product Info

12-Digit UPC
785901962717
GTiN
00785901962717
Product UPC
78590196271

Dimensions

Depth
4.37 Inch
Height
2.64 Inch
Warranty Length
18 mth
Width
4.02 in

Certifications and Compliance

CA Prop65 Warning
This product can expose you to chemicals including: Lead and lead compounds which is known to the State of California to cause Carcinogen & Reproductive harm. For more information go to www.p65warnings.ca.gov
Country of Origin
Mexico
