Product image for TES 9007ML02S0300 Limit switch, 9007, 240 VAC 10amp ml +options
Image thumbnail 0
Image thumbnail 1
Email

TES 9007ML02S0300 Limit switch, 9007, 240 VAC 10amp ml +options

Manufacturer: TES Electric | Catalog # 9007ML02S0300 | Cooper Electric Part # 575850
$136.50/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3 Product Brochure
Limit switch, 9007, 240 VAC 10amp ml +options

Technical Information

Action
Snap action;By 30? cam
Actuator
SPRING RETURN PARALLEL ROLLER PLUNGER STEEL -
Amperage
10 Amp
Applications
9007MS/ML,MINIATURE POTTED,PLUNGER HEAD
Body Material
Cast Zinc
Body Type
Fixed
Contact Configuration
NC-NO
Contact Material
Silver
Enclosure
NEMA 1 NEMA TYPE 250-NEMA 2 NEMA TYPE 250-NEMA 4 NEMA TYPE 250-NEMA 6 NEMA TYPE 250-NEMA 6P NEMA TYPE 250
Head Type
Plunger head
Material
Metal
Net Weight
1.2 lb
Number of Poles
1 Pole
Operating Cycles
100k
Operating Temperature
-40-220 Adegrees F
Size
0.62 in
Standard
E78403,LR 25490 Class 32 11 03
Storage Temperature
-40-220 degrees F
TC Connection
PRE-WIRED CABLE BOTTOM
Type
Limit switch
Voltage
6 A 120 Volt AC, A300 NEMA RATING DESIGNATION-3 A 240 Volt AC, A300 NEMA RATING DESIGNATION-5 A 28 Volt DC

Manufacturer Information

Brand
Telemecanique
Sub Brand
9007MS/ML

General Product Info

12-Digit UPC
785901719557
GTiN
00785901719557
Product UPC
78590171955
Weight
1.2 lb

Dimensions

Depth
0.62 Inch
Height
1.75-1.75 Inch
Warranty Length
18 mth
Width
1.56 in

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Certifications
CE,CSA,UL
Country of Origin
Mexico
