TES ZCKJ4104 Limit switch body with spring return rotary head, Limit switches XC Standard, ZCKJ, w/o lever, plug in, 2C/O, snap, Pg13

Manufacturer: TES Electric | Catalog # ZCKJ4104 | Cooper Electric Part # 549563
$232.30/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
Limit switch body with spring return rotary head, Limit switches XC Standard, ZCKJ, w/o lever, plug in, 2C/O, snap, Pg13

Technical Information

Action
Snap action;From left and right
Amperage
10 Amp
Applications
XCKJ
Body Material
Metal
Body Type
Plug-in body
Cable Entry
1 entry tapped for Pg 13.5 cable gland
Contact Configuration
2 C/O
Contact Material
Silver Plated Contacts
Enclosure
IP66
Net Weight
0.465 kg
Number of Poles
2 Pole
Number of Steps
2 3
Operating Cycles
5000000 CYCLES, DC-13 120 V, 4 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13 24 V, 10 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13 48 V, 7 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C
Operating Temperature
-25-70 Adegrees C STANDARD ENVIRONMENT
Size
2.36 in
Storage Temperature
-40-70 degrees C
TC Connection
SCREW-CLAMP TERMINALS 1 X 0.75...2 X 1.5 MMA
Type
Limit switch body with spring return rotary head
Voltage
3 A 240 Volt, AC-15, A300 EN/IEC 60947-5-1 APPENDIX A-0.27 A 250 Volt, DC-13, Q300 EN/IEC 60947-5-1 APPENDIX A

Manufacturer Information

Brand
Telemecanique
Sub Brand
ZCKJ

General Product Info

12-Digit UPC
389110662255
Environmental Conditions
STANDARD ENVIRONMENT
GTiN
03389110662252
Product UPC
78590166225
Weight
1.03 lb

Dimensions

Depth
60 mm
Height
109-109 mm
Warranty Length
18 mth
Width
43 mm

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Country of Origin
France
