Thomas & Betts MD1210F-2 Motor Disconnect

Manufacturer: ABB | Thomas & Betts | Catalog # MD1210F-2 | Cooper Electric Part # 493674
$4,061.25/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Installation / Instruction Manual Product Brochure
KUBE Female Copper Motor Pigtail Disconnect, Wire Size 12-10 AWG, Body Size 2, Die Color Code Yellow

Technical Information

Conductor Size
12-10 AWG
Contact Material
Copper
Material
Copper
Standard
UL E9809
Type
Motor Lead Female Disconnect
Voltage
600 Volt

Manufacturer Information

Brand
ABB
Sub Brand
Color-Keyed®

General Product Info

12-Digit UPC
786210789736
Color
Yellow
Finish
Tin Plated
GTiN
05415022247008
Product UPC
78621078973
Certifications
  • CSA
  • UL
Notes
  • Always use the same body size when selecting male and female disconnects. Use insulating boots matching the disconnect body size. To protect the connection from moisture and dirt, use sealing compound catalog number MDBOOT-SEAL.
Features
  • Quick disconnect - no knife cutting of melted tape, eliminating the risk of accidental cutting of wire insulation, resulting motor downtime and installer exposure. Meets or exceeds electrical and mechanical performance of bolted commections.
  • Female disconnects equipped with beryllium copper louvered contact bands for dependable connections.
  • Fast, snap-together assembly offers maximum labor savings. Not need for nuts, bolts and washers or insulating tape - simply slide on reusable boot.
