Product image for SQD 9001KT1LGG31 Push-to-test pilot
Image thumbnail 0
Image thumbnail 1
Email

SQD 9001KT1LGG31 Push-to-test pilot

Manufacturer: Square-D / Schneider | Catalog # 9001KT1LGG31 | Cooper Electric Part # 489099
$217.19/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet CAD Drawing #1 CAD Drawing #2 CAD Drawing #3 Product Brochure
This illuminated green push-to-test pilot light with integral LED provides an ergonomic and visual interface for your machines It is clearly distinguishable visually at a distance thanks to its illuminated head and clear color It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments It is easily installed into a standard 30mm diameter panel cut-outs and connected to control circuits with classic screw-clamp connections High performance International standards & certifications (Marine ABS certification, Type 1, 2, 3, 3R, 4, 6, 12 and 13)

Technical Information

Applications
9001K
Base
BA 9s
Bezel Material
Metal
Lens Type
Fresnel Plastic
Light Source
Green LED
Net Weight
0.21 kg
Operating Temperature
-25-70 Adegrees C
Size
1.18 in
Standard
CSA C22.2 No 14,EN/IEC 60947-1,EN/IEC 60947-5-1,EN/IEC 60947-5-4,JIS C 852,JIS C8201-1,JIS C8201-5-1,UL 508
Storage Temperature
-40-70 degrees C
Style
BA 9S,PUSH-TO-TEST
Type
Pilot light

Manufacturer Information

Brand
Square D
Sub Brand
9001K

General Product Info

12-Digit UPC
785901797609
Color
Green
Environmental Conditions
NEMA 1-NEMA 12-NEMA 13-NEMA 2-NEMA 3-NEMA 3R-NEMA 4-NEMA 6
Finish
Chromium
Fixture Type
GREEN LED
GTiN
00785901797609
Product UPC
78590179760
Shape
Round
Weight
0.46 lb

Dimensions

Height
70 mm
Warranty Length
18 mth
Width
54 mm

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Certifications
NEMA,UL 508
Country of Origin
Mexico
