Square D CA2KN31F7 110 VAC 10 Amp 4.5 VA 4-Pole 3NO 1NC IEC Control Relay

Manufacturer: Square-D / Schneider | Catalog # CA2KN31F7 | Cooper Electric Part # 439875
$47.66/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
TeSys K control relay, 4 contacts (3NO + 1NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 110V 50/60Hz AC control circuit, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -25/+50.C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium product (RoHS/REACh).

Technical Information

Amperage
10 Amp AT <= 50 ?C
Applications
Control circuit
Contact Configuration
3 NO + 1 NC
Contact Rating
<= 690 V <= 400 HZ
Enclosure
IP2X
Net Weight
0.18 kg
Operating Cycles
10000 cyc/h
Operating Temperature
-25-50 degrees C
Size
2.24 in
Standard
CSA C22.2 No 60947-4-1,EN/IEC 60947-4-1,GB/T 14048.4,JIS C8201-4-1,UL 60947-4-1
Storage Temperature
-50-80 degrees C
TC Connection
SCREW CLAMP TERMINALS 1 1.5-4 MMASOLID- SCREW CLAMP TERMINALS 2 1.5-4 MMASOLID- SCREW CLAMP TERMINALS 1 0.75-4 MMAFLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 0.75-4 MMAFLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 1 0.34-1.5 MMAFLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 0.34-1.5 MMAFLEXIBLE WITHOUT CABLE END
Type
Control relay
Voltage
690 Volt

Manufacturer Information

Brand
Schneider Electric
Sub Brand
CA2K;TeSys CAK

General Product Info

12-Digit UPC
389110428387
GTiN
03389110428384
Product UPC
78590199303
Weight
0.18 kg

Dimensions

Depth
2.24 in
Height
2.28 in
Warranty Length
18 mth
Width
1.77 in

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Certifications
CB Scheme,CCC,CE,CSA,EAC,UKCA,UL
Country of Origin
Indonesia
Inrush Power In VA
  • 30-30 VA (at 20 °C)
Connections Terminals
  • screw clamp terminals 1 1.5-4 mm²solid
  • screw clamp terminals 2 1.5-4 mm²solid
  • screw clamp terminal
ITH Conventional Free Air Thermal Current
  • 10 A (at 50 °C)
CAD
  • https://download.schneider-electric.com/files?p_Doc_Ref=CA2KN31F7_CAD&p_File_name=CA2KN31F7_3D.stp
  • https://download.schneider-electric.com/files?p_Doc_Ref=CA2KN31F7_CAD&p_File_name=CA2KN31F7_2D Front View.dwg
  • https://download.schneider-electric.com/f
Prop 65
  • WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Carbon Footprint Of The Installation Phase A5
  • 0.010778292366401048
  • 0 kg CO2 eq.
Carbon Footprint Of The End Of Life Phase C1 To C4
  • 0.3 kg CO2 eq.
  • 0.2979052988386399
Standards
  • EN/IEC 60947-5-1
  • GB/T 14048.5
  • UL 60947-5-1
  • CSA C22.2 No 60947-5-1
  • JIS C8201-5-1
Operating Time
  • 10...20 ms coil de-energisation and NO opening
  • 10...20 ms coil energisation and NO closing
  • 15...25 ms coil de-energisation and NC closing
  • 15...25 ms coil de-energi
Control Circuit Type
  • AC 50/60 Hz
UC Control Circuit Voltage
  • 110 V AC 50/60 Hz
Related Products
  • LA1KN22
  • LA1KN40
  • LA1KN31
  • LA1KN04
  • LA1KN13
  • LA2KT2U
  • LA4KE1FC
Carbon Footprint Of The Manufacturing Phase A1 To A3
  • 1 kg CO2 eq.
  • 0.9753347007368284
Protective Treatment
  • TC IEC 60068
UI Rated Insulation Voltage
  • 690 V IEC 60947
  • 750 V VDE 0110 group C
  • 690 V BS 5424
  • 600 V CSA C22.2 No 14
Market Segmentation
  • Commercial
  • Industrial
Persona Type Names
  • End User
  • Contractor
  • Original Equipment Manufacturer
  • OEM - Control Panelbuilder
  • Panel Builder
  • System Integrator
Add Ons
  • LA1KN22
  • LA1KN40
  • LA1KN31
  • LA1KN04
  • LA1KN13
  • LA2KT2U
Flame Retardance
  • V1 conforming to UL 94
  • requirement 2 conforming to NF F 16-101
  • requirement 2 conforming to NF F 16-102
Carbon Footprint Of The Use Phase B2 B3 B4 B6
  • 57 kg CO2 eq.
  • 56.65241524409139
Accessory Products
  • LA9D90
Persona Type Ids
  • EU
  • LC
  • OM
  • OM8
  • PB
  • SI
Carbon Footprint Of The Distribution Phase A4
  • 0.0699882448144537
  • 0.1 kg CO2 eq.
Tightening Torque
  • 1.3 N.m screw clamp terminals flat Ø 6 mm
  • 1.3 N.m screw clamp terminals Philips No 2 6 mm
  • 1.3 N.m screw clamp terminals Ph
Mechanical Robustness
  • vibrations contactor open2 Gn, 5...300 Hz IEC 60068-2-6
  • vibrations contactor closed4 G
Operating Altitude
  • 6561.68 ft (2000 m) without derating
Control Circuit Voltage Limits
  • drop-out: 0.2...0.75 Uc (at <50 °C)
  • operational: 0.8...1.15 Uc (at <50 °C)
Market Segmentation Id
  • COMMERCIAL
  • INDUSTRIAL
IRMS Rated Making Capacity
  • 110 A IEC 60947
Associated Fuse Rating
  • 10 A gG conforming to IEC 60947
  • 10 A gG conforming to VDE 0660
Hold In Power Consumption In VA
  • 4.5-4.5 VA (at 20 °C)
UE Rated Operational Voltage
  • <= 690 V <= 400 Hz
