Blackburn ADR60 Extruded Aluminum Lug

Manufacturer: Blackburn / Thomas & Betts | Catalog # ADR60 | Cooper Electric Part # 435909
$1,716.67/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page
Type ADR-ALCUL Single-Conductor, One-Hole Mount, Conductor Range Max 600 kcmil, Min 2 Str, 3/8 Inch Bolt Hole, Length 3-3/16 Inch, Tin Plated

Technical Information

Bolt Size
3/8 in
Conductor Size
2 AWG-600 kcmil
Conductor Type
Aluminum and Copper
Insulated?
No
Material
Aluminum
Number of Conductors
1
Standard
UL E9809
Type
Dual-Rated

Manufacturer Information

Brand
ABB
Sub Brand
Blackburn®

General Product Info

12-Digit UPC
783786610310
Finish
Tin Plated
GTiN
05414363147534
Product UPC
78378661031

Dimensions

Height
1-9/16 Inch
Length
3-3/16 Inch
Width
1 1/2 in
Features
  • Easy Installation - no special tools required.
Notes
  • 3/8 inch Hex Socket screw on sizes 500 kcmil and above.
  • UL 486B tested, AL9CU rated
