Square D HCR548612U 600 VAC 250 VDC 1200 Amp 3-Phase 3-Wire Panelboard Interior

Manufacturer: Square-D / Schneider | Catalog # HCR548612U | Cooper Electric Part # 424996
$11,213.00/ea
ea
Log in or register to view your price, purchase history, and more!
0

Not Available for Pickup at Ocean Opens Wednesday 7:00am ET
1 available

For Delivery

Order by Wednesday 5:00pm ET for delivery Thursday
Not in local stock *
Check another branch
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 Product Brochure
Square D™-brand I-Line™ circuit breaker power distribution panelboards are for use on AC or DC systems. The panels, labeled cULus (compliance to UL and CSA standards certified by UL) are also Underwriters Laboratories® (UL®) Listed under File E33139. Service entrance panelboards meeting the requirements of CSA are available in Canada factory-assembled only. I-Line circuit breaker panelboards are available as 400–1200 A main lugs only and 100–1200 A main circuit breakers. This HCR-U I-Line panelboard interior is a 1200A and has Universal Mains. The dimesnions are 86 in (H), 44 in (W). This product is certified to cULus & CE standards. This product comes with an 18 month warranty.

Technical Information

Amperage
1,200 Amp
Applications
PANELBOARD INTERIOR
Current
1200 Amp
Line Rated Current
1200 A
Material
Aluminum
Net Weight
124.74 kg
Operating Temperature
PER UL
Size
108 in
TC Connection
BOTTOM
Type
PANELBOARD INTERIOR
Voltage
600//250 VAC//VDC

Manufacturer Information

Brand
Square D
Sub Brand
I-LINE

General Product Info

12-Digit UPC
785901001355
GTiN
00785901001355
Product UPC
78590100135
Weight
124.74 kg

Dimensions

Depth
8.85 Inch
Height
66.03 Inch
Length
108 Inch
Warranty Length
18 mth
Width
36.91 in

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Country of Origin
USA
Prop 65
  • WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
