3M FP301-1/2-48"-Clear-12 Pcs Thin Wall Shrink Tubing
$3.39/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer 3M
Mfg Catalog # FP301-1/2-48-CLEAR-12-PCS
Cooper Electric Part # 765916

Specifications

  • Flame Retardant: No
  • Expanded Inner Diameter: 0.5 Inch
  • Operating Temperature (Celsius): -55 to 135 Degrees Celsius
  • Minimum Expanded Tubing I. D.: 1 Inch
  • UL Bug Temperature (Fahrenheit): 257 Degrees Fahrenheit
  • Recovered Inner Diameter (metric): 6.4 mm
  • Size (metric): 12.7 mm
  • Color: Clear
  • Size: 0.50 Inch
  • Material: Polyolefin
  • Agency Approvals: CSA
  • Recovered Inner Diameter: 0.25 Inch
  • UL Bug Temperature (Celsius): 125 Degrees Celsius
  • Expanded Inner Diameter (metric): 12.70 mm
  • RoHS 2011/65/EU Compliant: Yes
  • Length: 48 Inch
  • Product Form: 48 in (1.22 m) sticks
  • UL Bug Voltage: 600 Volt
  • Shrink Ratio: 2:1
  • Operating Temperature (Fahrenheit): -67 to 275 Degree Fahrenheit
  • RoHS EU Comments: RoHS 2011/65/EU compliant without exemption
  • Tubing Type: Single (Thin) Wall

Documents

Overview

UPC 05112859592
Product Description 3M Heat Shrink Tubing FP-301 offers an outstanding balance of electrical, physical and chemical properties for a wide variety of industrial and military applications.
GTiN 00051128595923
Length 48 in
Color Clear
Type Single (Thin) Wall
Thickness 0.025
Shrink Ratio 2:1
Family Brand Name 3M
Outside Diameter 0.5 in
Dielectric Strength 900 V/mil
Inside Diameter 0.25
Size 0.50 in
Operating Temperature -55 To 135 C
Material Polyolefin
Flame Retardant No
