Product image for ABB LBH30-G PVC CTD PULL ELBW 90D H
Email

ABB LBH30-G PVC CTD PULL ELBW 90D H

Manufacturer: Ocal / Thomas & Betts | Catalog # LBH30-G | Cooper Electric Part # 393320
$1,275.83/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet
PVC Coated Pulling Elbow for Hazardous Locations, 90 Degree Bend, With Pressure-Sealing Sleeves Seal Connections, Pipe Size 1 Inch/27 Metric, Gray Iron, Dark Gray

Technical Information

Applications
Used in Rigid Conduit to Act as Pull Outlets for Conductors
Material
Iron
Size
1 in
TC Connection
90 Degree Bend
Trade Size
1 Inch; 27 mm
Type
Complete Rail for Conduit System Support

Manufacturer Information

Brand
ABB

General Product Info

12-Digit UPC
704508391812
Color
Gray
Finish
PVC Coated
GTiN
00704508391812
Product UPC
70450839181
Features
  • Domed cover permits easy conductor bends, relieves strain on insulation
  • Shipped complete with elbow, cover and cover screws.
  • Nominal .040 in. (40 mil) PVC coating bonded to exterior
  • Coated with a nominal .002 in. (2 mil) blue urethane on both interior and exterior
  • Cover openings on an angle, permitting conductors to be pulled straight through hubs from either direction
  • Taper threaded hubs with integral bushings
  • Pressure-sealing sleeves seal connections
Application
  • Suitable for hazardous locations use in Class III
  • Act as pull outlets especially for conductors that are stiff due to large size or type of insulation
  • Provide for conductor entrance to motors
  • Suitable for hazardous locations use in Class I, Division 1 & 2, Group D
  • Suitable for hazardous locations use in Class II, Division 1, Groups E, F, G; Class II, Division 2, Groups F, G
  • Make 90° bends in conduit system, allowing straight pull in either direction
  • Provide for conduit service entrance to buildings
Notes
  • Dimensional values are prior to PVC coating
  • Ratings are prior to PVC coating
  • Metric size designator (ANSI C80.1-1994)
