ABB 61950 BIMETAL PIN CONN AL250 CU

Manufacturer: ABB | Thomas & Betts | Catalog # 61950 | Cooper Electric Part # 381668
$16,951.68/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Product Brochure
Bi-Metal Pin Connectors with Insulating Cover, 600V, Aluminum Cable Size 250 kcmil to Copper Pigtail Wire Size 3/0 AWG, Tin Plated, Die Code 66, Die Color Code White

Technical Information

Conductor Size
250 kcmil (AL)/3/0 AWG (CU)
Connection Type
Ferrule Terminal
Insulation Material
Neoprene
Material
Aluminum
Standard
UL E63167
Temperature Rating
90 degrees C
Type
Bimetallic
Voltage
600 Volt
Wire Size
000 AWG

Manufacturer Information

Brand
ABB
Sub Brand
Color-Keyed®

General Product Info

12-Digit UPC
786210619507
Color
White
Finish
Electro-Tin Plated
GTiN
00786210619507
Housing Material
Aluminum
Product UPC
78621061950
Features
  • Upgrades connection by eliminating cold flow and oxidation of aluminum.
  • Barrel prefilled with joint compound.
  • Converts an aluminum cable into a two-sizes-smaller copper pigtail.
Notes
  • Copper Wire/Aluminum Body. Neoprene insulator with 600V dielectric rating.
