Product image for Square D LA1KN31 575 VAC 10 Amp 3NO 1NC Screw Clamp Terminal Auxiliary Contact Block
Image thumbnail 0
Image thumbnail 2
Email

Square D LA1KN31 575 VAC 10 Amp 3NO 1NC Screw Clamp Terminal Auxiliary Contact Block

Manufacturer: Square-D / Schneider | Catalog # LA1KN31 | Cooper Electric Part # 375353
$20.65/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals (except LP4K, LP5K, CA4K). It provides 3NO+1NC contacts rated up to 10A 690V AC, connection by screw clamp terminals. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh).

Technical Information

Applications
CA3K-CA2K
Coil Voltage
<= 690 V AC <= 400 HZ
Contact Configuration
3 NO + 1 NC
Contact Rating
10 A 50 AC
Net Weight
0.045 kg
Operating Temperature
-25-50 Adegrees C
Range
TeSys
Size
1.38 in
Standard
CSA C22.2 No 60947-5-1,EN/IEC 60947-5-1,GB/T 14048.5,JIS C8201-5-1,UL 60947-5-1
Storage Temperature
-50-80 degrees C
TC Connection
SCREW CLAMP TERMINALS 1 0.34-1.5 MMAFLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 1 0.75-4 MMAFLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 1 1.5-4 MMASOLID- SCREW CLAMP TERMINALS 2 0.34-1.5 MMAFLEXIBLE WITH CABLE END- SCREW CLAMP TERMINALS 2 0.75-4 MMAFLEXIBLE WITHOUT CABLE END- SCREW CLAMP TERMINALS 2 1.5-4 MMASOLID
Type
Auxiliary contact block
Voltage
690 Volt

Manufacturer Information

Brand
Schneider Electric
Sub Brand
TeSys K

General Product Info

12-Digit UPC
389110500090
GTiN
03389110500097
Product UPC
78590189864
Weight
0.045 kg

Dimensions

Depth
35 mm
Height
30 mm
Warranty Length
18 mth
Width
38 mm

Certifications and Compliance

Certifications
CB Scheme,CCC,CE,CSA,UKCA,UL
Country of Origin
USA
