Thomas & Betts A18-8F #8 Bolt Hole 22-16 AWG Wire Range Metallic Non-Insulated Fork Terminal

Manufacturer: ABB | Thomas & Betts | Catalog # A18-8F | Cooper Electric Part # 348012
$129.20/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Product Brochure
Non-Insulated Fork Terminal, Length 0.75 Inches, Width 0.31 Inches, Bolt Hole #8, Wire Range #22-16 AWG, Copper, Tin Plated, 100 Pieces

Technical Information

Barrel Type
Brazed Seam
Conductor Size
22-16 AWG
Flamability Class
Rated V-0 Per UL94
Insulation Type
Non-Insulated
Material
Copper
Standard
UL E9809
Stud Size
#8
Temperature Rating
150 degrees C
Terminal Type
A
Type
Short Sleeve
Voltage
600 Volt
Wire Size
22-16 AWG

Manufacturer Information

Brand
ABB
Sub Brand
Sta-Kon®

General Product Info

12-Digit UPC
786210803012
Color
Metallic
Finish
Electro Tin Plated
GTiN
05414363935346
Product UPC
78621080301

Dimensions

Height
3 Inch
Thickness
.03 in
Width
1.63 in
Certifications
  • CSA
  • UL
Features
  • These non-insulated fork terminals are made of electrolytic copper for high conductivity. They can be installed with crimping tools having a single indentor or double indentor (recommended for solid wire). Serrated barrel increases grip on wire.
