Square D 60157 240 Volt 5 Amp Miniature Circuit Breaker

Manufacturer: Square-D / Schneider | Catalog # 60157 | Cooper Electric Part # 342512
$269.00/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Safety Data Sheet CAD Drawing #1 Product Brochure
Schneider Electric,MINIATURE CIRCUIT BREAKER 240V 5A,10 to 14 times ampere rating,12...240 V AC-125 V DC-60 V DC,12...240 V AC-125 V DC-60 V DC,35mm DIN rail,5A,73 mm,Box Lug Box Lug,C60,C60 UL489,miniature circuit-breaker,C60,Multi 9,D,IP40 (Case) - IP20 (Terminals),UL 489 - CSA C22.2 No.5

Technical Information

Actuator
TOGGLE
Amperage
5 Amp
Applications
DISTRIBUTION
Barrel Length
Long
Barrel Shape
Standard
Barrel Type
Long
Conductor Size
250 kcmil
Die Code
71
Enclosure
IP40 (CASE) - IP20 (TERMINALS)
Insulated?
No
Interrupt Rating
6, 10, 20 kAIC
Material
Aluminum
Mounting Type
Clip-On
Number of Holes
1 Hole
Number of Poles
2 Pole
Number of Studs
1
Operating Temperature
-30-70 Adegrees C
Standard
CSA C22.2 No 5,EN/IEC 60947-2,GB 14048.2,UL 489
Strip Length
0.55 in
Stud Size
5/8 in
TC Connection
TUNNEL TYPE TERMINAL TOP OR BOTTOM) 2.5-25 MMA AWG 14...AWG 4) - RIGID
Tongue Angle
Straight
Tongue Width
Standard
Trip Range
10 TO 14 TIMES AMPERE RATING
Trip Type
THERMAL-MAGNETIC
Type
MINIATURE CIRCUIT-BREAKER
Voltage
125 Volt
Wire Size
250 kcmil

Manufacturer Information

Brand
Square D
Sub Brand
C60 UL489,MULTI 9 C60

General Product Info

12-Digit UPC
785901411550
Color
Gray
Finish
Tin Plated
GTiN
00785901411550
Product UPC
78590141155
Shape
Round
Weight
0.49 lb

Dimensions

Depth
2.87 Inch
Height
4.21 Inch
Length
73 mm
Warranty Length
18 mth
Width
1.42 in

Certifications and Compliance

Certifications
CCC,CSA,IEC,UL
Country of Origin
France
Notes
  • Dimensions given for reference only. Dimensions may vary up to .030.
