ANACON 34251 1-1/2 UA-EFST-EF-HTUA-

Manufacturer: Anamet / Anaconda | Catalog # 34251 | Cooper Electric Part # 339618
$5.54/ea
ft
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Buy American Compliant Buy American Compliant Product Spec Sheet Safety Data Sheet
Thermoplastic PVC Jacket UL approved 1-1/2" UA Gray 50 ft carton

Technical Information

Applications
Standard
Bend Radius
5.5 in
Conduit Type
UA
Material
Steel
Radius
140 mm
Size
1 1/2 in
Trade Size
1-1/2 Inch
Type
Liquid-tight flexible metal conduit

Manufacturer Information

Brand
ANAMET Electrical, Inc.
Sub Brand
Sealtite

General Product Info

12-Digit UPC
714118342517
Color
Gray
Finish
Pvc Coated
GTiN
00622620342515
Weight
112 lb

Dimensions

Inside Diameter
1.600 in
Length
50 Foot
Outside Diameter
1.900 in

Certifications and Compliance

Buy American Compliant
Y
Certifications
CSA Certified,RoHS WEEE,UL Listed
NEC Articles
  • Article 250.118 (6) Equipment Grounding
  • Article 300.22 (D) Information Technology Equipment
  • Article 350 Liquid-Tight Flexible Metal Conduit (LFMC)
  • Article 501.10 (B) (2) Class I Div. 2
  • Article 502.10 (A) (2) and (B) (2) Class II Div. 1 & 2
  • Article 503.10 (A) (3) and (B) Class III Div. 1 & 2
  • Article 620.21 Elevator Wiring Methods
  • Article 645.5 (E) (2) Under Raised Floors
Application
  • Where UL Listing is Required and Conduit Grounding is Necessary
  • Temperature Range: -40F to +176F (-40C to +80C)
Installation
  • Conduit used with standard liquid-tight connector for easy installation. IP 67 Rated when installed with approved connectors.
  • Approved for both exposed and concealed locations. Rated for temperature ranges -40F to + 176F (-40C to +80C).
  • Approved as an equipment grounding conductor in sizes 3/8\" through 1-1/4\" if the total grounding path is 6 ft. or less and the circuit conductors are protected by over 20 amps for 3/8\" and 1/2\" and 60 amps or less for 3/4\" through 1-1/4\".
  • Suitable for use in hazardous locations per NEC Articles 501 Class I Div. 2, Article 502 Class II Div. 1 & 2, Article 503 Class III Div. 1 & 2.
  • Manufactured in a full range of trade sizes from 3/8\" through 4\".
  • Approved for direct burial and in concrete trade sizes 3/8\" through 4\".
  • Complies with UL Standard 360 File No. E18917; CSA C22.2 File No. 158897; and NEC Article 350.
