Product image for Panduit PN14-10R-3K Ring Terminal, Black, Nylon, 14-16 AWG, #10 Stud, PK3000
Email

Panduit PN14-10R-3K Ring Terminal, Black, Nylon, 14-16 AWG, #10 Stud, PK3000

Manufacturer: Panduit Corp | Catalog # PN14-10R-3K | Cooper Electric Part # 314231
$1,240.93/m (1000 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Buy American Compliant Buy American Compliant Product Spec Sheet Product Catalog Page Engineering Drawing
The PN14-10R-3K Reel Smart™ Terminal is a continuously molded, nylon insulated, ring terminal. The continuously molded design allows for consistent and reliable processing through Panduit applicators. The metal insulation grip sleeve crimps to wire insulation, providing protection and strain relief to the crimp joint for high vibration applications. Barrel serrations assure good wire contact and maximum tensile strength.

Technical Information

Barrel Length
0.43 in
Barrel Type
Grip Sleeve
Color Coding
Blue
Conductor Size
14 AWG
Enclosure
Ring shape
Material
Copper
Max Operating Temperature
105 degrees C
Size
#10
TC Connection
Standard
Temperature Rating
221 F
Tongue Thickness
0.03 in
Tongue Width
0.31 in
Type
Ring Terminal
Voltage
600 Volt
Wire Size
14 AWG

Packaging

Pkg Qty
3000

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
Reel Smart™

General Product Info

12-Digit UPC
074983806270
Color
Blue
Finish
Tin Plated
GTiN
00074983806270
Product UPC
07498380627

Dimensions

Overall Length
0.86 in
Width
0.31 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
Mexico
Standards and Certifications
  • Standards Met: cULus Listed 587H E52164, CSA Certified LR31212
