Product image for Panduit DNF18-250FIMB-L Nylon Fully Insulated Male Disconnect
Email

Panduit DNF18-250FIMB-L Nylon Fully Insulated Male Disconnect

Manufacturer: Panduit Corp | Catalog # DNF18-250FIMB-L | Cooper Electric Part # 305810
$405.41 /c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
BAA | Buy American Compliant BAA | Buy American Compliant Engineering Drawing Product Spec Sheet
The vibration resistant male tab disconnect is made of brass and is nickel-plated. It is fully insulated in a red, nylon oversized housing. It has a tab size of 0.250 x 0.032" (6.3 x 0.8 mm) and supports a wire range of 22-18 AWG (0.5-1.0 mm.). It is 0.91" (23.1 mm) long and 0.45" (11.4 mm) wide. The disconnect has a standard barrel configuration and a butted seam barrel. It comes in bottles of 50.

Technical Information

Barrel Type
Butted Seam
Color Coding
Red
Conductor Size
22 AWG
Material
Brass
Max Operating Temperature
105 degrees C
Standard
CSA,E2186,UL
TC Connection
Standard
Temperature Rating
221 degrees F
Type
Disconnect
Voltage
600 Volt
Wire Size
22-18 AWG

Packaging

Pkg Qty
50

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
Pan-Term®

General Product Info

12-Digit UPC
074983824199
Color
Red
Finish
Plated
GTiN
00074983824199
Product UPC
07498382419
UNSPSC
39121409

Dimensions

Height
0.34 Inch
Overall Length
0.91 in
Width
0.45 in

Certifications and Compliance

BAA | Buy American Compliant
Y
Country of Origin
Mexico
Standards and Certifications
  • Standards Met: UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153
