Panduit DNH10-250FI-E Disconnect, Female, Yellow, HS, 250 x .032",12-10AWG,20

Manufacturer: Panduit Corp | Catalog # DNH10-250FI-E | Cooper Electric Part # 289984
$689.11/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Buy American Compliant Buy American Compliant Product Spec Sheet Product Catalog Page Engineering Drawing
The female disconnect is made of brass and is tin-plated. It is fully insulated in yellow heat shrink. It has a tab size of 0.250 x 0.032 (6.3 x 0.8 mm) and supports a wire range of 12-10 AWG (4.0-6.0 mm?). It is 1.44" (36.6 mm) long and 0.35" (8.9 mm) wide. The disconnect has a standard barrel configuration and a sleeved barrel. It comes in bags of 20.

Technical Information

Barrel Type
Sleeved Barrel
Color Coding
Yellow
Conductor Size
10 AWG
Material
Brass
Max Operating Temperature
110 degrees C
TC Connection
Standard
Temperature Rating
230 F
Type
Loose Piece Disconnect
Voltage
600 Volt
Wire Size
12-10 AWG

Packaging

Pkg Qty
20

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
Pan-Term

General Product Info

12-Digit UPC
074983818310
Color
Yellow
Finish
Tin Plated
GTiN
00074983818310
Product UPC
07498381831
UNSPSC
39121409,39121409

Dimensions

Depth
0.96 Inch
Height
0.22 Inch
Overall Length
1.44 in
Width
0.35 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
