Product image for Panduit DNH14-250FIB-Q 0.25 Inch 16 to 14 AWG Heat Shrink Fully Insulated Female Disconnect
Email

Panduit DNH14-250FIB-Q 0.25 Inch 16 to 14 AWG Heat Shrink Fully Insulated Female Disconnect

Manufacturer: Panduit Corp | Catalog # DNH14-250FIB-Q | Cooper Electric Part # 289979
$721.09/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Buy American Compliant Buy American Compliant Product Spec Sheet Product Catalog Page Engineering Drawing
The female disconnect is made of brass and is tin-plated. It is fully insulated in blue heat shrink. It has a tab size of 0.250 x 0.032 (6.3 x 0.8 mm) and supports a wire range of 16-14 AWG (1.5-2.6 mm.). It is 1.44" (36.6 mm) long and 0.35" (8.9 mm) wide. The disconnect has a standard barrel configuration and a butted seam barrel. It comes in bags of 25.

Technical Information

Barrel Type
Butted Seam
Color Coding
Blue
Conductor Size
14 AWG
Material
Brass
Max Operating Temperature
110 degrees C
TC Connection
Standard
Temperature Rating
230 F
Type
Disconnect
Voltage
600 Volt
Wire Size
16-14 AWG

Packaging

Pkg Qty
25

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
Pan-Term®

General Product Info

12-Digit UPC
074983818297
Color
Blue
Finish
Tinned
GTiN
00074983818297
Product Type
Terminals
Product UPC
07498381829
UNSPSC
39121409

Dimensions

Depth
0.84 Inch
Height
0.22 Inch
Length
1.44 Inch
Overall Length
1.44 in
Width
0.35 in

Certifications and Compliance

ARRA Compliant
Yes
Buy American Compliant
Y
CE Compliant
No,No
Country of Origin
USA
Hazmat Flag
No
Standards and Certifications
  • Standards Met: UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153
