Product image for KLRK XSX-22 SWITCH 1GANG 2P DEAD 3/
Email

KLRK XSX-22 SWITCH 1GANG 2P DEAD 3/

Manufacturer: Killark | Catalog # XSX-22 | Cooper Electric Part # 287712
$316.19/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet
XSX Series - Aluminum Dead-End Single Gang 2-Pole, Single Phase Manual Motor Starting Switch Unit - Without Overload Protection - Hub Size 3/4Inch

Technical Information

Applications
Provides manual starting and stopping of small AC or DC motors. Motor running protection when overload heaters are used. XSX Series (without overload protection) is ideally suited for across-the-line applications where a positive disconnect means is requi
Coil Voltage
2 HP @ 115 VAC; 2 HP @ 200-230 VAC; 3 HP @ 460-575 VAC.
Enclosure Material
Stainless Steel
Enclosure Type
Aluminum enclosure
Frequency
60 Hz
Horsepower
3 hp
Material
Aluminum
Number of Phases
1 Phase
Number of Poles
2 Pole
Power Rating
2 HP @ 115 VAC; 2 HP @ 200-230 VAC; 3 HP @ 460-575 VAC.
Reset Type
Lever
Size
1 1/2 in
Type
Non-Reversing
Voltage
600 Volt

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Killark

General Product Info

12-Digit UPC
783936933443
GTiN
00783936933443
Product UPC
78393693344

Dimensions

Height
4 Inch
Length
7-1/2 Inch
Width
5.75 in

Certifications and Compliance

Country of Origin
Mexico
Features
  • XSX Series (without overload protection) are ideally suited for across the-line applications where a positive disconnect means is required.
  • Enclosures are cast copper-free aluminum alloy.
  • Operating shaft is stainless steel.
  • Multiple gang assemblies available in combination with pilot lights, pushbuttons and switches on request.
  • Ground flange joint between bolted cover and box provide required flame path.
  • Provisions for padlocking switch in either ON or OFF position is standard.
  • Enclosures are cast copper-free aluminum alloy. Operating shaft is stainless steel. Ground flange joint between bolted cover and box provide required flame path. Provisions for padlocking switch in either \"ON\" or \"OFF\" position is standard.
