Burndy KK4A40U4N Aluminum Universal Terminal, 4 Conductor, 4 Hole, 300-800 kcmil, 1/2" Stud, 175" Stud Hole Spacing, 8 Screws, Al/Cu Rated, Tin Plated

Manufacturer: Burndy | Catalog # KK4A40U4N | Cooper Electric Part # 265966
$827.99 /ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
BAA | Buy American Compliant BAA | Buy American Compliant Product Spec Sheet
Aluminum Universal Terminal, 4 Conductor, 4 Hole, 300-800 kcmil, 1/2" Stud, 1.75" Stud Hole Spacing, 8 Screws, Al/Cu Rated, Tin Plated.

Technical Information

Applications
For Aluminum and Copper Conductors
Connection Type
Parallel Set-Screw
Material
Aluminum
Number of Conductors
4
Number of Wires
4 Wire
Plated?
Yes
Plating Type
Tinned
Type
Bolted Lugs & Terminals

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Burndy

General Product Info

12-Digit UPC
781810601099
GTiN
00781810601099
Product UPC
78181060109

Dimensions

Height
1.89 Inch
Hole Size
0.56 in
Length
6.19 Inch
Overall Length
6.19 in
Width
8.3 in

Certifications and Compliance

BAA | Buy American Compliant
Y
Country of Origin
USA
CSA
No
Features
  • Dual rated panelboard lugs constructed from high strength extruded aluminum alloy , electro tin-plated to provide low contact resistance
