Product image for Pass & Seymour PS5466-XHG 20 Amp 250 VAC 2-Pole 3-Wire NEMA 6-20P Black and Clear Nylon Polarized Straight Blade Plug
Image thumbnail 0
Image thumbnail 1
Email

Pass & Seymour PS5466-XHG 20 Amp 250 VAC 2-Pole 3-Wire NEMA 6-20P Black and Clear Nylon Polarized Straight Blade Plug

Manufacturer: Pass & Seymour / Legrand | Catalog # PS5466XHG | Cooper Electric Part # 263778
$53.06/ea
ea
Log in or register to view your price, purchase history, and more!
15 20
125 250 277
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Brochure
Straight Blade Plug 2-Pole 3-Wire 20A 250V Hospital Grade

Technical Information

Amperage
20 Amp
Applications
Commercial
Conductor Size
18-10 AWG
Grade
Hospital
Material
Nylon
NEMA
6-20P
Number of Poles
2 Pole
Number of Wires
3 Wire
Size
2.2"
Type
Straight Blade
Voltage
250 Volt
Wire Size
10 AWG

Manufacturer Information

Brand
Legrand
Sub Brand
Pass & Seymour

General Product Info

12-Digit UPC
785007236811
Color
Black
GTiN
00785007236811
Product UPC
78500723681
UNSPSC
39121402

Dimensions

Depth
1.752 Inch
Height
1.516 Inch
Length
1.752 Inch
Width
1.358 in

Certifications and Compliance

Certifications
CULUS,FEDSPEC
Country of Origin
Mexico
Features
  • Unit arrives completely ready-to-wire, cuts installation time significantly.
  • Nylon housing provides impact and chemical resistance.
  • Rugged two-piece cord grip provides more uniform cord retention.
  • Internal dust shield keeps terminals free of contaminants.
  • Tri-drive assembly screws are standard on Hospital Grade plugs and connectors (angle plugs not included).
  • All 3-wire terminals located on the same plane, allows for quick wire termination from any angle.
  • Heavy-duty brass alloy blades and contacts, resist heat rise, provide excellent conductivity.
  • Cord-grip screws recessed to protect installer against screwdriver head slippage.
  • For covering patents, see www.legrand.us/patents.
Certifications
  • Federal Spec Listed
  • cULus Listed
