Product image for Leviton 55054 125/250 Volt 30 Amp 3-Pole 4-Wire NEMA 14-30R 2 Hp Black Thermoplastic Surface Mount Straight Blade Receptacle
Image thumbnail 0
Image thumbnail 1
Email

Leviton 55054 125/250 Volt 30 Amp 3-Pole 4-Wire NEMA 14-30R 2 Hp Black Thermoplastic Surface Mount Straight Blade Receptacle

Manufacturer: Leviton Mfg Co | Catalog # 55054 | Cooper Electric Part # 25387
$46.24/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Safety Data Sheet
Built of durable thermoplastic, Leviton Power Receptacles . come equipped with heavy-gauge, double-wire copper alloy contacts. To ensure correct and speedy wiring, terminals have ID markings.

Technical Information

Amperage
30 Amp
Applications
For Commercial Application
Body Material
Thermoplastic
Conductor Size
4 AWG
Connection Type
Side Wired
Current
30 Amp
Dielectric
2000 V
Dielectric Strength
2000 V (Min)
Face Material
Thermoplastic
Flamability Class
Rated V-2 Per UL 94
Grounding
Grounding
Horsepower
2 hp
Material
Thermoplastic
Mounting Type
Surface
NEMA
14-30R,WD-6
Number of Poles
3 Pole
Number of Wires
4 Wire
Operating Temperature
-40 degrees C
Rated Insulation Voltage
2000 V
Size
4.82 H x 2.68 W x 24 D IN
Standard
ANSI C-73
TC Connection
Side Wired
Temperature Rating
-40 degrees C to 60 degrees C
Temperature Rise
150 %
Terminal Size
4 AWG
Type
Straight Blade
Voltage
125/250 Volt
Wire Count
4
Wire Size
14-6 AWG

Manufacturer Information

Brand
Leviton

General Product Info

12-Digit UPC
078477100240
Color
Black
Environmental Conditions
Flammability (Rated V-2 Per UL94)
GTiN
00078477100240
Product UPC
07847710024

Dimensions

Warranty Length
10 yr
Additional Information
  • Power Rating 2 HP
  • Wire Size up to 4 AWG
  • Material Galvanized Steel (Strap), Thermoplastic (Face)
  • Operating Temperature Rating -40 to 60 Deg C
  • Flammability Rating UL 94-V2
  • Application Industrial, School, Hospital and Commercial Office Building
  • Applicable Standard ANSI C73, NOM 057, NEMA WD-6, ISO 9001
Features
  • Heavy Gauge, Double Wipe Copper Alloy Contacts
  • Easy to Wire Terminals Accept up to #4 AWG Conductor
  • Terminals Marked for Easy Identification and Fast Wiring
