WAG 811-431 3-POLE CC FUSE HOLDER WITH INDICAT

Manufacturer: Wago | Catalog # 811-431 | Cooper Electric Part # 2255578

$111.37/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
2-Conductor Fuse Holder for Class CC cylindrical fuses, 3-pole, with blown fuse indication, 600 VAC/VDC, for DIN-rail 35 x 15 and 35 x 7.5, 16 mm., CAGE CLAMP®, light gray colour. Ensure that the strip lengths are between 12 mm and 13 mm when connecting conductors to this fuse terminal block. This product features conductor terminals and utilizes CAGE CLAMP®. Our highly-rated and maintenance-free CAGE CLAMP® connection makes it easy to connect all conductor types without having to prepare the conductor. For example, you don't need to crimp ferrules.

Technical Information

Actuator
Operating Tool
Conductor Material
Copper
Conductor Size
6 AWG
Current
30 Amp
Flamability Class
V0
Insulation Material
Polyamide
Mounting Type
DIN-35 Rail
Operating Temperature
85 degrees C
Strip Length
0.51 in
Voltage
600 Volt

Manufacturer Information

Brand
Wago

General Product Info

12-Digit UPC
044918107048
Color
Gray
Product UPC
04491810704
Weight
1.111 g

Dimensions

Height
4.134 Inch
Width
2.067 in

Certifications and Compliance

Country of Origin
China
