Product image for Hubbell HBL7302C 60 Amp 3-Phase 120/208 VAC 4-Pole 4-Wire NEMA 18-60P Black Nylon Straight Blade Plug
Image thumbnail 0
Image thumbnail 1
Email

Hubbell HBL7302C 60 Amp 3-Phase 120/208 VAC 4-Pole 4-Wire NEMA 18-60P Black Nylon Straight Blade Plug

Manufacturer: Hubbell Wiring Device | Catalog # HBL7302C | Cooper Electric Part # 216112
$213.54/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Installation / Instruction Manual
Straight Blade Devices, Male Plug, Heavy Duty, Industrial/Commercial Grade, Angled, 4-Pole 4-Wire Non-Grounding, 60A 3 Phase 120/208V AC, 18-60P, Black, Single Pack.

Technical Information

Amperage
60 Amp
Applications
Industrial/Commercial
Conductor Size
12-4 AWG
Cord Type
All Portable
Current
60 Amp
Horsepower
7.5 hp
Material
Nylon
NEMA
18-60P
Number of Phases
3 Phase
Number of Poles
4-4 Pole
Number of Wires
4,4
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
File E2186,UL,UL Standard 498
TC Connection
Terminal Screws
Type
Insulgrip
Voltage
120/208 Volt
Wattage
12480 Watt
Wire Count
4
Wire Size
12-4 AWG

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Straight Blade Devices

General Product Info

12-Digit UPC
783585015378
Color
Black
GTiN
00783585015378
Product UPC
78358501537
Weight
0.8 lb

Dimensions

Height
2.88 Inch
Length
4.13 Inch
Width
2.88 in

Certifications and Compliance

Country of Origin
USA
Features
  • Heavy Duty
  • Industrial/Commercial Grade
  • Angled
