Erico 534007 Flexibar Advanced, 250 A, 4 Layers, 0.61" x 0.031", 97.91 kcmil, 6.56' long

Manufacturer: Erico, Inc | Catalog # 534007 | Cooper Electric Part # 1895609
$192.77/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Product Brochure
Flexible busbar with Advanced Technology design; thin layers of tinned electrolytic copper with high-resistance, halogen free, low smoke and flame retardant insulation. Flexibar Advanced 2 m long 4X15,5X0,8 mm.

Technical Information

Applications
Power Connections
Material
Copper
Type
nVent ERIFLEX Flexibar Flexible Busbar

Manufacturer Information

Brand
nVent Eriflex
Sub Brand
ERIFLEX

General Product Info

12-Digit UPC
782856937395
Finish
Tinned
GTiN
00782856937395
Product UPC
78285693739
Weight
1.02 kg

Dimensions

Length
6.56-6.56 Foot
Certifications
  • EN 45545-2 EN 45545-2
  • IEC 60695-2-12 IEC 60695-2-12
  • IEC 61439-1 IEC 61439-1
  • IEC 61439-1 Class II IEC 61439-1 Class II
  • ISO 5659-2 ISO 5659-2
  • Bureau Veritas ACE 14/163/02
  • UL UL94-V0
  • CE, ERIFLEX FLEXADV EN 61439-1
  • ERIFLEX UV IEC 60364-5-52, ISO 4892-2
  • UR ANSI/UL 67, ANSI/UL 891
  • cUR CSA C22.2 No. 29, CSA C22.2 No. 244
  • CSA CSA C22.2 No. 0, CSA C22.2 No. 210
  • UL (IEC) UL 2885 - IEC 60754-1, IEC 60754-2, IEC 62821-1 Annex B, IEC 61034-2
  • UR ANSI/UL 758
  • CSA C22.2 No 210
  • IEC Voltage Certification IEC 61439-1; IEC 62271-1; EN50264-3-1
Features
  • Thin layers of tinned electrolytic copper formed into a stack
  • Full range from 19.5 mm² up to 1200 mm² and 125 A to 2800 A
  • Insulated by high-resistance, halogen free, flame retardant and low smoke material with less than 20% contact with conductor for high flexibility
  • Easily bent, folded, and twisted, improving assembly flexibility, shortening connections, and decreasing footprint
  • Dramatically smaller and more flexible than comparable cable based on ampacity
  • Better power density than cable with lower skin effect ratio
  • Connections made by punching and bolting directly through the copper laminates or clamping onto the end of the nVent ERIFLEX Flexibar
  • No lugs needed, reducing installation time and improving resistance to vibration
  • Weight savings and material savings compared to wire alternatives
  • Reduces total installation cost
  • Traceability codes and designation part numbers printed on insulation
  • Conforms to NF EN 45545 obtaining an HL3 classification for chapters R22 and R23
  • 100% production dielectric tested
  • RoHS compliant
  • Tinned copper allows for copper or aluminum conductor connections
  • On request, can be manufactured with other colors (typically with Orange sleeve for battery connection)
  • Compliant to ISO 6469-1 (Electrically propelled road vehicles - Part 1: Rechargeable energy storage system) - Section 6.2.2 Vibrations
  • UL® 758 Appliance Wiring Material, Model Style 11992
