Product image for Square D LC2K09107B7 575 VAC 9 Amp 3-Pole 1NO Slip-On Terminal Full Voltage Reversing IEC Contactor
Image thumbnail 0
Image thumbnail 2
Image thumbnail 3
Image thumbnail 4
Image thumbnail 5
Email

Square D LC2K09107B7 575 VAC 9 Amp 3-Pole 1NO Slip-On Terminal Full Voltage Reversing IEC Contactor

Manufacturer: Square-D / Schneider | Catalog # LC2K09107B7 | Cooper Electric Part # 186283
$194.92 /ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning CAD Drawing #1 CAD Drawing #2 Product Spec Sheet Product Catalog Page CAD Drawing #3
Reversing contactor, TeSys K, 3P, AC-3, lt or eq to 440V 9A, 1 NO, 24VAC coil

Technical Information

Applications
CONTROL,RESISTIVE LOAD-MOTOR CONTROL
Coil Voltage
24 V AC 50/60 HZ,POWER CIRCUIT 690 V AC 50/60 HZ-SIGNALLING CIRCUIT <= 690 V AC 50/60 HZ
Contact Configuration
1 NO,3 NO
Contact Rating
20 A 50 AC POWER CIRCUIT-10 A 50 AC SIGNALLING CIRCUIT
Impedance
3 MOhm - Ith 20 A 50 Hz For Power Circuit
Net Weight
0.39 kg
Operating Cycles
3600 cyc/h
Operating Temperature
-25-50 degrees C
Range
TeSys
Size
57 MM,58 MM,90 MM
Standard
CSA C22.2 No 60947-4-1,EN/IEC 60947-4-1,GB/T 14048.4,JIS C8201-4-1,UL 60947-4-1
Storage Temperature
-50-80 degrees C
TC Connection
FASTON TERMINALS 2 2.8 MM- FASTON TERMINALS 1 6.35 MM
Type
Reversing contactor
Voltage
690 Volt

Manufacturer Information

Brand
Schneider Electric
Sub Brand
TESYS K

General Product Info

12-Digit UPC
389110492753
GTiN
03389110492750
Product UPC
78590187038
Weight
0.39 kg

Dimensions

Depth
57 mm
Height
2.28 in
Warranty Length
18 mth
Width
3.54 in

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Certifications
CB Scheme,CCC,CE,CSA,EAC,UKCA,UL
Country of Origin
France
Features
  • Designed to meet needs of various applications under 16A AC-3
  • Optimized size to save customer cabinet space
  • Wide range of accessaries to satisfy different customer usage
  • Easier to install and operate with multi-standard screws
  • Environmental performance of the product
  • Widely used for industry, infrastructure and building applications
  • Designed for simple control systems
Prop 65
  • WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Accessory Products
  • LA9D90
Related Products
  • LR2K0314
  • LR2K0316
  • GV2LE14
  • GV2ME14
