ILSCO 25004 UL/CSA Listed 1/8 Inch Diameter Thin Wall Heat Shrink

Manufacturer: Gardner Bender | Catalog # 25-004 | Cooper Electric Part # 1793657
$5.98/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page
ILSCO Heat Shrinkable Tubing, Thin Wall, Polyolefin material, UL 224 Recognized, C22.2 No. 198.1, Copper/Aluminum Primary Conductor 20 Str - 26 Str and 20 Sol - 26 Sol, rated for 600 V, Disk dispenser, primary color Black, 96 in cut length, 0.062 IN recovered OD,

Technical Information

Applications
For Shrink Wrap
Dielectric Strength
600 V/Mil
Shrink Ratio
2:1
Standard
CSA,E2186,UL
Type
HSTW:THIN HEAT SHRINK
Voltage
600 Volt
Wire Size
0.128 mm

Manufacturer Information

Brand
Ilsco
Sub Brand
ClearChoice

General Product Info

12-Digit UPC
783669421200
Color
Black
GTiN
00032076002534
Product UPC
03207600253

Dimensions

Height
0.938 Inch
Length
8 Foot
Width
.547 in
Overview
  • Designed to require fewer turns to reach required torque and meet or exceed UL pull out and dielectric test requirements
  • Square-wire zinc-plated spring instantly adjusts to the shape and size of the splice
  • Flame-retardant properties resist heat distortion up to 105 degrees Celsius/221 degrees Fahrenheit
  • High-dielectric shell features deep skirt design to prevent exposure of bare wire
  • Rated at 600V max in building wire and at 1000V max in lighting, fixtures/luminaries and signs
  • Copper to copper connections only
