SQD NSYPLA12123G Floor standing pol

Manufacturer: Square-D / Schneider | Catalog # NSYPLA12123G | Cooper Electric Part # 1758326
$1,243.47 /ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Brochure Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
Thalassa PLA floor standing polyester enclosure. 1250x 1250x 320 mm. Sealed top and bottom part, assembled with side parts. 4 points lock, 5 mm double-bar insert. 2 doors. Right and left 120. opening. Accessible front and rear. Polyester reinforced with fibreglass. Grey RAL 7035. IP65, IK10, NEMA (1,2,12,13). 960.C fire resistance.

Technical Information

Body Type
Sealed Top And Bottom Part Assembled With Side Parts
Door Type
Solid Front
Lock Type
5 mm
Material
Fiberglass,Polyester
Number of Doors
2
Standard
IEC 62208,UL 508 A
Storage Temperature
-35-90 degrees C

Manufacturer Information

Brand
Schneider Electric

General Product Info

12-Digit UPC
606480774556
Color
Gray RAL 7035)
GTiN
03606480774553
Product UPC
60648077455

Dimensions

Enclosure Depth
320 mm
Enclosure Height
1250 mm
Enclosure Wdth
1250 mm
Height
1250 mm
Warranty Length
18 mth
Width
1250 mm

Certifications and Compliance

Certifications
DNV Marine,UL/cUL Listed,Veritas
Country of Origin
Spain
Features
  • Versatile floor-standing enclosure suitable for various applications.
  • Polyester reinforced with fiberglass ensures durability and resistance.
  • Easy access design with removable doors and rear panels.
  • Four-point lock with a double-bar insert ensures enhanced security.
  • Resistant to fire up to 960°C, offering robust protection.
  • High impact, dust, and water resistance, providing complete protection.
  • Class II electrical insulation ensures safety and shock prevention.
  • Able to operate efficiently in a wide range of temperatures.
