SQD 725BXXBM4L-120A Power relay, SE

Manufacturer: Square-D / Schneider | Catalog # 725BXXBM4L120A | Cooper Electric Part # 1736838
$14.42/ea
ea
Order in multiples of 10 (pack qty)
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
This 725 power relay belongs to the Schneider Electric Harmony electromechanical relays range. 725 power relay has a LED status indicator with Flat (Faston type) terminals supporting Plug-in socket mounting. It.s a 25A 2 NO contact configuration mechanic

Technical Information

Contact Material
Silver Alloy
Impedance
2 MOhm
Input Voltage
...132 V
Line Rated Current
25 A
Net Weight
120 g
Operating Temperature
-20-55 degrees C
Rated Power
1.3 kW
Short Circuit Current
3 kA
Standard
IEC 60947-1,UL 60947-4-1A
Storage Temperature
-55-100 degrees C
Strip Length
8 mm

Manufacturer Information

Brand
Schneider Electric

General Product Info

12-Digit UPC
785901163138
GTiN
03606480278945
Product UPC
78590116313

Dimensions

Depth
2.09 in
Height
1.97 in
Length
8 mm
Width
1.3 in

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproduc
Certifications
CE,CSA,UL
Country of Origin
China
Connections Terminals
  • quick-connect terminal strips 6.35 x 0.8 mm
IE Rated Operational Current
  • 25 A at 277 V AC (on resistive load) conforming to UL
  • 25 A at 277 V AC (on resistive load) c
CAD
  • https://download.schneider-electric.com/files?p_Doc_Ref=725BXXBM4L-120A_3D&p_File_name=725BXXBM4L-120A_3D.stp
  • https://download.schneider-electric.com/files?p_Doc_Ref=725BXXBM4L-120A_3D&p_File_name=725BXXBM4L-120A-SchneiderElectricMagnecraft-2DBottomVie
Rated Power In HP
  • 1 hp 120 V AC
  • 2 hp 277 V AC
Prop 65
  • WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproduc
Rated Power In W
  • 1.3 kW 120 V tungsten
Maximum Switching Voltage
  • 240 V CE
  • 277 V UL
UC Control Circuit Voltage
  • 120 V AC 50/60 Hz
Accessories
  • 70-725-1
  • 16-700DIN
  • 16-DCLIP-1
Electrical Durability
  • 100000 cycles resistive IEC
Accessory Products
  • 16-700DIN
  • 16-DCLIP-1
  • 70-725-1
Input Voltage
  • 102...132 V AC 50/60 Hz
Dielectric Strength
  • 4000 V AC between coil and contact
  • 2000 V AC between poles
Minimum Switching Current
  • 100 mA 5 V DC
Associated Fuse Rating
  • 32 A gG at 400 V coordination type 2 for power circuit
  • 32 A gG at 400 V coordination type
Local Signalling
  • LED indicator
  • flag
