SQD LV431756 3P3T MA220 NSX250H

Manufacturer: Square-D / Schneider | Catalog # LV431756 | Cooper Electric Part # 1720635
$2,904.00/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
This Compact NSX250H is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for motor protection applications. The breaking capacity (Icu) is 70kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 220A rating magnetic trip unit (MA). MA trip unit provides an adjustable magnetic protection for instantaneous tripping. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX250H is part of Schneider Electric EcoStruxure Power architecture.

Technical Information

Enclosure
IP40 CONFORMING TO IEC 60529
Line Rated Current
220 A
Mounting Type
Fixed
Net Weight
2.4 kg
Standard
EN/IEC 60947
Storage Temperature
-50-85 degrees C
Type
CIRCUIT BREAKER

Manufacturer Information

Brand
Schneider Electric
Sub Brand
COMPACT

General Product Info

12-Digit UPC
785901116097
GTiN
03606480014772
Product UPC
78590111609

Dimensions

Depth
86 mm
Height
161 mm
Warranty Length
18 mth
Width
105 mm

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Certifications
CCC,EAC,Marine
