Product image for TES XUAH0515S Photoelectric sensors XU, XUA, diffuse, Sn 0.05 m, 12...24 VDC, M8
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

TES XUAH0515S Photoelectric sensors XU, XUA, diffuse, Sn 0.05 m, 12...24 VDC, M8

Manufacturer: TES Electric | Catalog # XUAH0515S | Cooper Electric Part # 1638323
$223.10/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
This photo-electric sensor is part of the XU Application range. It is designed for assembly applications. It is a metal case, cylindrical, threaded M8 x 1 receiver, with DC supply and solid-state output. This sensor features an M8 connector. 0.05m nominal sensing distance. 3-wire, PNP, NO function. Thru-beam system with infrared transmission.

Technical Information

Amperage
<= 100 MA OVERLOAD AND SHORT-CIRCUIT PROTECTION)
Applications
-
Current
25 mA
Enclosure
IP65 CONFORMING TO IEC 60529-IP67 CONFORMING TO IEC 60529,NICKEL PLATED BRASS
Enclosure Material
Brass
Material
Metal
Net Weight
0.5 kg
Operating Cycles
<= 1000 Hz
Operating Temperature
-25-55 degrees C
Output
1 NO;PNP;Solid state;Discrete
Sensing Range
0.05-0.05 M DIFFUSE,> 0...0.98 FT (> 0...0.3 M)
Size
0.31 in
Storage Temperature
-30-70 degrees C
TC Connection
1 MALE CONNECTOR M8, 3 PINS
Type
Diffuse;Photo-electric sensor;Cylindrical M8;Application assembly
Voltage
12...24 Volt DC REVERSE POLARITY PROTECTION

Manufacturer Information

Brand
Telemecanique

General Product Info

12-Digit UPC
785901738503
GTiN
03389110427233
Product UPC
78590173850

Dimensions

Chain Cable Diameter
3.5 mm
Diameter
8 mm
Length
48 mm
Warranty Length
18 mth

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Certifications
CE,CULus
