3M 7000021415 3M™ Scotchlok™ IDC C

Manufacturer: 3M | Catalog # 7000021415 | Cooper Electric Part # 1621019
$2,158.93/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Product Brochure
3M™ Scotchlok™ Electrical Insulation Displacement Connectors electrically connect a tap wire end through a run wire to insulates the connection. These connectors make inline, pigtail and tap splices on 14 gauge solid or stranded wires with no wire stripping. They have a maximum insulation O.D. diameter of 0.145 inches (3.68 millimetre) and an operating temperature of 194 degrees Fahrenheit (90 degrees Celsius). The suggested application tool for this connector is the 3M™ Scotchlok™ Crimping Tool, E-9BM.

Technical Information

Conductor Size
18 AWG
Connection Type
Double Run Or Tap
Insulation Material
Polypropylene
Material
Copper
Max Operating Temperature
194.0 degrees F
Temperature Rating
194 F
Type
Insulation Displacement
Voltage
32 Volt
Wire Size
22-18 AWG (Tap) 18-14 AWG (Run)

Manufacturer Information

Brand
Scotchlok
Sub Brand
Scotchlok

General Product Info

12-Digit UPC
054007061298
Color
Red
GTiN
00054007061298
Product Type
Double Run Or Tap
Product UPC
05400706129

Certifications and Compliance

Country of Origin
USA
Features
  • Red, polypropylene-insulated connector is suitable for tap or parallel splicing
  • Suitable for use in light fixtures, appliances and other electrical OEM applications
  • 951 accommodates 22 to 18 AWG solid/stranded, 952 accommodates 18 to 14 AWG solid/stranded and 953 accommodates 12 AWG solid/stranded
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
