Erico 556670 MBJ Grounding and Bonding Braid, Tinned Copper, 150 A Ampacity, 49.34 kcmil, 3.937", 0.413" Hole

Manufacturer: Erico, Inc | Catalog # 556670 | Cooper Electric Part # 1604307
$14.88/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Product Brochure
Flat Tinned Copper Grounding Braid. MBJ25-100-10, 150 A Ampacity, 49.34 kcmil (25 mm²), 3.937" (100 mm), 0.413" (10.5 mm) Hole.

Technical Information

Applications
Grounding and Bonding; Power Connections
Material
Copper
Type
Grounding and Bonding Braids

Manufacturer Information

Brand
nVent Eriflex
Sub Brand
ERIFLEX

General Product Info

12-Digit UPC
782856578543
Finish
Tinned
GTiN
00782856578543
Product UPC
78285657854
Weight
0.03 kg
Features
  • Complete range of earth/ground flexible connections from 6 - 100 mm² (11.84 - 197.35 kcmil) cross section and from 100 - 500 mm (3.937\" - 19.685\") length
  • Integral palm, without tin or crimped lugs for superior electrical contact and tensile strength resistance
  • Resistant to vibration and fatigue, reducing maintenance
  • Provides weight savings, material savings and lower impedance when compared to similar lugged cables with insulation
  • Ready to use out of the box, eliminates the need for cutting, stripping, crimping and punching
  • Quick and easy to install
  • Recommended by the EMC/EMI directives and less impedance than cables
  • EAC compliant
  • RoHS compliant
  • Compliant to ISO 6469-1 (Electrically propelled road vehicles - Part 1: Rechargeable energy storage system) - Section 6.2.2 Vibrations
Certifications
  • UKCA, ERIFLEX MBJ EN 61439-1
  • cUL CSA C22.2 No. 41
  • UL ANSI/UL 467
