Square D QOB350VH Miniature Circuit Breaker 50A 240V 3Ph , Bolt-On

Manufacturer: Square-D / Schneider | Catalog # QOB350VH | Cooper Electric Part # 157929
$475.20/ea
ea
Log in or register to view your price, purchase history, and more!
0

Not Available for Pickup at Ocean Opens Wednesday 7:00am ET
8 available

For Delivery

Order by 5:00pm ET for delivery tomorrow
Not in local stock *
Check another branch
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page Product Brochure
Square D™ QO™ and QOB Miniature Circuit Breakers, QOB350VH, come in bolt-on mounted version and in a complete range of amperages and interrupting ranges to fit into various QO distribution panels. With breacking capacity to 22kA. UL listed.

Technical Information

Amperage
50 Amp
Applications
HACR rated
Circuit Breaker Type
Standard
Conductor Size
8-2 AWG
Current
50 Amp
Interrupt Rating
22 kAIC
Line Rated Current
50 A
Mounting Type
Bolt-on
Net Weight
0.499 kg
Number of Poles
3 Pole
Operating Temperature
40 Adegrees C
Short Circuit Current
22 kA
TC Connection
Box lugs
Type
Miniature circuit-breaker
Voltage
120 Volt
Wire Size
AWG 8...AWG 2 copper or aluminium

Manufacturer Information

Brand
Square D
Sub Brand
QO

General Product Info

12-Digit UPC
785901054825
GTiN
00785901054825
Product UPC
78590105482
Weight
0.499 kg

Dimensions

Depth
74 mm
Height
79 mm
Length
2.91 Inch
Warranty Length
18 mth
Width
57 mm

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Certifications
CSA,UL Listed
Country of Origin
Mexico
Prop 65
  • WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Compatible Products
  • HLO1
  • NQ442L2C
  • QO1PL
  • QO70AN
  • NQ430L2C
  • QO2DTI
  • QO2PAF
  • QON3B
  • NQ430L1C
  • QO1PJ15
  • QO2DTIM
  • NQ42L2C
  • QOFSHALB12
  • NQ442L4C
  • NQ442L2
  • NQ418L1C
  • NQ454L2C
  • NQ30L2C
  • NQ18L1C
  • NQ430L2
