Applications
0.5 HP 120 V AC-1 HP 240 V AC
Dielectric Strength
4 kV AC for input/output;4 kV AC for input or output to case
Input Current
10 mA at 12 V DC
Maximum Load Current
0.1510 A
Operating Temperature
-40-80 Adegrees C
Power Factor
0.5 (with maximum load)
Response Time
0.5 cycle (turn-on);0.5 cycle (turn-off)
Standard
CSA C22.2 No 14-13,IEC 60950-1,IEC 62314,UL 508
Storage Temperature
-40-125 degrees C
TC Connection
SCREW TERMINALS 0.2...3.3 MMA, AWG 24...AWG 12) WITH CABLE END INPUT-SCREW TERMINALS 0.5...5.26 MMA, AWG 20...AWG 10) WITH CABLE END OUTPUT-SCREW TERMINALS 0.2...3.3 MMA, AWG 24...AWG 12) WITHOUT CABLE END INPUT-SCREW TERMINALS 0.5...8.26 MMA, AWG 20...AWG 8) WITHOUT CABLE END OUTPUT-FORKED TYPE TAG CONNECTORS 9.2 X 4 MM INPUT-RING LUGS 9.2 X 4 MM INPUT-FORKED TYPE TAG CONNECTORS 11.7 X 4.5 MM OUTPUT-RING LUGS 11.7 X 4.5 MM OUTPUT
