HWDK USB4ACI USB CHRGR 4 PORT 5AMP

Manufacturer: Hubbell Wiring Device | Catalog # USB4ACI | Cooper Electric Part # 1502938
$64.49/ea
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet Product Catalog Page Installation / Instruction Manual
This device will communicate with mobile devices to determine what voltage is required and provide 5V or 9V, based on the make and model. The two USB Type A ports offer high power at 5 volts.

Technical Information

Amperage
5 Amp
Applications
USB Charging
Conductor Size
14-10 AWG
Current
5 Amp
Material
Thermoplastic
Number of Poles
2 Pole
Number of Wires
3 Wire
Size
Standard Sized Product
Style
Style Line Decorator
Temperature Rating
Maximum continuous 75degrees C; minimum -40degrees C (w/o impact)
Type
USB Charger
Voltage
125 Volt
Wire Size
14-10 AWG

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
USB Chargers

General Product Info

12-Digit UPC
883778308963
Color
Ivory
GTiN
00883778308963
Product Series
4 Port Outlet
Product UPC
88377830896

Dimensions

Height
1.9 Inch
Length
4.2 Inch
Width
2.2 in

Certifications and Compliance

Country of Origin
China
Features
  • Four USB ports 5 Amp, 2 Type A and 2 Type-C USB, 5V DC, class 2.0
  • Fast charge enabled modulates up to 9 volts
  • Switch activated port door
  • when open enables power
  • when closed, all power is switched off, for a zero no-load draw
  • Green LED indicator to show USB power available
  • Compatible with USB 1.1/2.0/3.0 devices, including Apple® products
