Blackburn IPC5041 Insulated Piercing Connector

Manufacturer: Blackburn / Thomas & Betts | Catalog # IPC5041 | Cooper Electric Part # 149035
$22,191.73/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Out of stock, please contact your sales representative for availability, pricing and lead times
Product Spec Sheet
Type IPC - Talon Insulation Piercing Connector for Conductor Range Main: 500-350 AWG, 240-185 MM sq., Tap: 4/0-4 AWG, 90-25 MM sq.

Technical Information

Applications
For Copper to Copper, Copper to Aluminum and Aluminum to Aluminum Applications
Conductor Size
350 - 500 kcmil Main/Primary, 4/0-4 AWG Tap/Secondary
Number of Ports
1
Standard
UL E9809
Temperature Rating
90 degrees C
Type
Insulated
Voltage
600 Volt

Manufacturer Information

Brand
Thomas & Betts (T&B)
Sub Brand
Blackburn®

General Product Info

12-Digit UPC
783786331130
Color
Black
GTiN
05415022505764
Product UPC
78378633113
Used With
90 C Maximum
Features
  • Self-insulated for hot line applications. Six sizes cover range from #10 to 500 kcmil.
  • For copper-to-copper, copper-to-aluminum and aluminum-to-aluminum applications (insulated conductor only). Performs as splice or tab for non-tension applications up to 600 volts, depending on size of connector.
