Panduit F1X4WH6 Narrow Slotted Wiring Duct, PVC, 1" x 4" x 6ft, White

Manufacturer: Panduit Corp | Catalog # F1X4WH6 | Cooper Electric Part # 136473
$38.49/ea
ft
Order in multiples of 6 (pack qty)
Log in or register to view your price, purchase history, and more!
Narrow Slot Duct Wide Slot Duct Duct Cover
Out of stock, please contact your sales representative for availability, pricing and lead times
Buy American Compliant Buy American Compliant Product Spec Sheet Product Catalog Page Engineering Drawing Product Brochure
The F1X4WH6 Panduct Lead-Free PVC Narrow Slot Wiring Duct features a narrow slot/finger design that closely matches the spacing of high-density components. Upper and lower scorelines allow for easy finger/sidewall section removal. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 122.F (50.C). Mounting holes provided. Lead-free PVC. 4.1" x 1.25" (104.1 mm x 31.8 mm) and 6' (1.83 m) long. Cover sold separately. Color White. 6 per package.

Technical Information

Applications
For Indoor Applications
Material
PVC
Mounting Type
Standard
Size
32.0 x 104.1 mm
Slot Size
5 mm Pitch
TC Connection
Standard Mounting Holes
Type
Type F

Packaging

Pkg Qty
6

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
Panduct

General Product Info

12-Digit UPC
074983375189
Color
White
GTiN
00074983375189
Product UPC
07498337518

Dimensions

Depth
104.1 mm
Height
4.1 Inch
Length
1.8 m
Overall Length
6 ft
Thickness
0.11 in
Width
32 mm

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
Standards and Certifications
  • Standards Met: RoHS Compliant, UL Recognized, CE Compliant, BABA Compliant
